The DMC-1ProCCCD is a high performance instrument typically used by research for Fluorescence,Darkfield,Phase Contract or other demanding imaging applications.
This unit features:
- 1.4 Mpixel Sony 2/3" CCD sensor
- Improved signal to noise performance from Peltier Cooling of the sensor
- Exposure settings from 0.25ms to 4min
- High quality image acquistion
- Excellent price / performance
- Multi operating system compatibility
Optional accessories include a large range of adapters to suit the major brands of microscopes
SPECIFICATIONS:
| Sensor | 1.4Mpixel 2/3" Sony CCD (6.45 x 6.45um pixels) |
| Spectral range | 380 to 650nm (with IR filter) |
| Frame rate | 15fps @ 1360 x 1024 |
| White balance | ROI / Manual (per control software |
| Cooling | Peltier type ; 20C below ambient temperature |
| Operating Temp | 10C to 50C (with 30% to 80% RH) |
| Interface | USB2.0 |
| Operating system | WinXP ; Vista ; Win7 ; Win 8 (32 & 64 bit) ; Mac OS-X ; Linux |
| Processor requ. | Intel Core 2 or higher |
| Processor speed | 2.8Ghz or higher |
| RAM | 2Gb or higher |
| Adapter | Industry standard C-mount adapter |
Standard outfit
- 1 x Camera
- 1 x Power supply
- 1 x USB cable
- 1 x Software CD with drivers & software
OPTEK DMC-1ProCCCD
- Product Code: DMC-1ProCCCD
- Availability: In Stock
-
$0.00
- Ex Tax: $0.00
